Test: Icekimo 240VGA køler
Køling d. 06. December. 2016, skrevet af bauner 0 Kommentarer. Vist: 19671 gange.
Specifikationer
De tekniske specifikationer er taget direkte fra IC-Cooling´s hjemmeside.
| VGA Compatibility | 58.4*58.4mm; 53.3*53.3mm |
| Mounting holes | GTX 10 Series, GTX 9 Series; ATI R9 400/300/200 Series, etc. |
| TDP | 300W |
| Radiator dimensions | 274×120×27mm |
| Radiator material | Aluminum |
| Tube material | Sleeved Rubber Tubing |
| Tube length | 380 mm |
| Waterblock dimensions | ?65×30mm |
| Cold plate material | Copper |
| Pump current | 0.25A |
| Pump speed | 2300 rpm |
| Pumps bearing | Ceramic bearing |
| Pump Life Expectancy | 50.000 hrs |
| Pump noise level | 25dB(A) |
| Fan dimensions | 120×120×25mm |
| Included fans | 2 pcs |
| Fan speed | 700~1600±RPM |
| Max. air flow | 62CFM |
| Max. static pressure | 1.78mmH2O |
| Noise | 18~26.4dB(A) |
| Rated voltage | 12VDC |
| Operating voltage | 10.8~13.2VDC |
| Started voltage | 7VDC |
| Rated current | 0.18A |
| Power input | 2.16W |
| bearing type | Hydraulic Bearing |
Design på næste side
