Test: NZXT H500i
Kabinetter d. 24. September. 2018, skrevet af bauner 0 Kommentarer. Vist: 10203 gange.
Specifikationer
Jeg har, som altid, kopieret specifikationerne direkte fra producentens hjemmeside.
| Dimensions | W: 210mm H: 435mm D: 428mm (without feet) W: 210mm H: 460mm D: 428mm (with feet) |
| Material(s) | SECC Steel and tempered glass |
| Weight | 7 Kg |
| Motherboard Support | Mini-ITX, MicroATX, and ATX |
| I/O Ports | 2 x USB 3.1 Gen 1 1 x Audio/Mic |
| Filters | Front right side panel, bottom front and PSU intake |
| Expansion Slots | 7 |
| Smart Device | 3 x Fan channels with Max 10W per channel output* 1 x RGB LED port support up to 4 x HUE+ LED strips or 5 x Aer RGB fans Built-in noise detection module *Note: If a splitter is used, fan control is regulated depending on the fan connected to the 4-pin port. Do not use low-noise adapters. |
| System Requirements | PC with open internal USB 2.0 port and Windows® 10 operating system recommended. Internet connection is needed to download CAM. Some CAM features require Internet access, a valid email address and acceptance of our current Terms of Service. |
| Vertical GPU Mount | Support 2 slot GPU. Riser card with 30cm length recommended. Riser card not included. |
| Drive Bays | 2,5": 2 + 1 3,5": 2 + 1 |
| Radiator Support | Front: Up to 280mm Rear: 120 mm |
| Fan Support | Front: 2 x 120/2 x 140mm Top: 1 x 120mm (1 Aer F120 Case Version included) / 1 x 140mm Rear: 1 x 120mm (1 Aer F120 Case Version included) |
| Fan Specs | Aer F120 (Case Version) Speed: 1200 + 200 RPM Airflow: 50.42 CFM Noise: 28 dBA Bearing: Rifle Bearing |
| Clearance | Cable Management: 19-23mm GPU Clearance: Up to 381mm CPU Cooler: Up to 165mm Front Radiator: 60mm Rear Radiator: 60mm Reservoir & Pump: Up to 180mm (Along cable bar), Up to 86mm (Along bottom panel) |
| Warranty | 2 years |
| Model Number | CA-H500W-W1 |
Udvendigt design på næste side.
